TO BE CONTINUED 3 Wooden buildings and indoor climate in summer. Computer simulation of thermal comfort.

09/06/2023

Computer simulation of thermal comfort.

- in terms of overheating in the transparent part, the importance of attenuation and phase shift is lost

- the dominant influence is in the transparent part of the building envelope

- research has shown that the impact of the storage core is overestimated

- on the contrary, night cooling is important

DTNSE construction systems


Total U value 0.15 W / (m2 .K)

Comparison of normative compositions

1. On the left:

Massive brick wall with contact insulation

THICKNESS 50cm

2. On the right:

Wood-based frame construction with lightweight posts.

THICKNESS 34 cm

Comparison of total energy intensity

Total energy intensity

Comparison of CEN building materials - production, transport, assembly:



                     Energy consumption               Total energy             Index relative

                     in the production of 1 ton         consumption per        to wood

                     of material (MJ)                          1 ton of built-in

                                                                             material (MJ)

Coniferous wood      626                                637                                   1

Burnt brick                 3216                              2149                                  3

Cement                     2592                              2754                                 4

Concrete                   3024                              3773                                 6

Steel                          13932                             15001                               24

Aluminum                 78624                            80028                             126


Comparison of total energy intensity

Comparative criterion   Silicate construction   Wooden building

---------------------------------------------------------------------------------------------------------------

Floor plan dimension                           96,76m2                           95,35m2

Wall thickness                                      40cm                                 28cm

U - value circuit. mantle                       0,53 W/(m2K)                    0,22 W/(m2K)

Annual heat demand for heating        13 500 kWh                       8700 kWh

Energy consumption for production   253  760 kWh                   120 080 kWh

Equivalent                                             23,7  CO2ekv                     9,1  CO2ekv



prof. Ing. Jozef Štefko, PhD., Technical University of Zvolen, Faculty of Wood Science
